Swaging 5 Piece Set

Yellow Jacket 60476 Swaging Punch Set – 5-Piece, Heat-Treated Alloy Steel

The Yellow Jacket 60476 swaging punch set is engineered for expanding soft copper tubing to facilitate same-size tube joining without fittings. The five-piece set includes precision-machined punches sized for 1/4″, 5/16″, 3/8″, 1/2″, and 5/8″ OD copper, covering common HVAC and plumbing tubing sizes used in residential and light commercial applications.

Product Features

• Heat-Treated Alloy Steel: Constructed from hardened, plated alloy steel to ensure dimensional accuracy and long service life under repeated use.
• Size Range: Includes swaging punches for 1/4″, 5/16″, 3/8″, 1/2″, and 5/8″ tubing, supporting common line sets and system branches.
• One-Piece Construction: Machined from solid stock for durability and consistent expansion results.
• Made in USA: Manufactured domestically for contractors who require dependable tool performance.

Technical Specifications

• Tool Type: Swaging punch set (5 pieces)
• Compatible Tubing: Soft copper
• Sizes Included: 1/4″, 5/16″, 3/8″, 1/2″, 5/8″
• Material: Heat-treated and plated alloy steel
• Country of Origin: USA

Application Notes

This set is intended for use with hammer-assisted manual swaging. Apply lubricant to the tubing interior before swaging to reduce friction and tube deformation. Ensure tubing is properly annealed and deburred prior to expansion. Avoid use on Type L or K hard-drawn copper without prior annealing, as this may result in cracking or distortion.

Contractor Use Considerations

• Suitable for HVACR system fabrication, line set modification, and refrigeration loop repairs requiring swaged copper connections.
• Compact set can be transported to job sites and used without powered equipment.
• Reduces the need for couplings or additional brazed joints in field-assembled piping systems.
