Milwaukee 48-22-4263 – Close Quarters Tubing Cutter Set

The Milwaukee 48-22-4263 Close Quarters Tubing Cutter Set is engineered for clean, accurate cuts in copper tubing where space limitations prevent the use of standard cutters. This set includes cutters for 1/2″, 3/4″, and 1″ outer diameter pipe, each designed to access restricted areas encountered in plumbing, mechanical, and HVAC installations.

Each cutter features a compact, directional grip design for improved control and alignment during rotation. Integrated chrome-plated rollers provide corrosion resistance and stability during cutting, while strategically placed weep holes allow water drainage to protect internal components from moisture damage.

Key Product Features

• Low-Profile Design – Optimized for restricted clearance applications
• Dedicated Cutter Sizes – Includes individual tools for 1/2″, 3/4″, and 1″ copper tubing
• Directional Grip – Provides operator feedback on swing direction and enhances control
• Chrome-Plated Rollers – Improves durability and rust resistance
• Weep Holes – Prevent moisture retention, extending tool life in wet environments
• Replaceable Cutter Wheels – Serviceable components reduce long-term tool replacement cost

Technical Specifications

• Model: 48-22-4263
• Includes: 1/2″, 3/4″, and 1″ close quarters cutters
• Storage Case: Included
• Overall Dimensions (Case): 6.9″ L x 4.3″ W x 2.0″ H
• Body Construction: Metal with protective plating

Application Use

Ideal for use in confined areas such as behind wall cavities, under sinks, or between framing members. Suitable for Type L and Type M copper tubing. Apply even pressure and rotate until separation is complete. Cutter wheels can be replaced as needed to maintain cut quality over time.
